Pneumatic 4-ported 3-position valve template - Mac

"An air-operated valve is a type of power operated valve that uses air pressure against a piston or diaphragm to produce linear or circular movement to operate a valve. Types are 2-way, 3-way and 4-way. The 2 way air-operated valves can be either normally closed or normally opened." [Air-operated valve. Wikipedia] The Mac template "Pneumatic 4-ported 3-position valve" for the ConceptDraw PRO diagramming and vector drawing software is included in the Mechanical Engineering solution from the Engineering area of ConceptDraw Solution Park. www.conceptdraw.com/solution-park/engineering-mechanical
Pneumatic directional control valve
Pneumatic directional control valve, four-port, three-position, valve,
