The vector stencils library "Audio and video connectors" contains 94 symbols of audio and video connectors and device silhouettes. Use these jacks and plugs clipart icons for drawing hook up diagrams in the ConceptDraw PRO diagramming and vector drawing software extended with the Audio and Video Connectors solution from the Engineering area of ConceptDraw Solution Park. www.conceptdraw.com/solution-park/engineering-audio-video-connectors
