HVAC ductwork - Vector stencils library
- Rect. duct, closed ends
- Rect. duct, open 1 end
- Rect. duct, open both ends
- Circ. duct, closed ends
- Circ. duct, open 1 end
- Circ. duct, open both ends
- Branch duct, rectangular
- Branch duct, circular
- Variable bend
- Miter bend
- Y junction
- 3 way junction
- Junction 1
- Beveled junction, rect. duct, rect. branch
- Beveled junction, rect. duct, circ. branch
- Beveled junction, circ. duct, rect. branch
- Beveled junction, circ. duct, circ. branch
- Transition, rect. to rect.
- Transition, rect. to circ.
- Transition, circ. to rect.
- Transition, circ. to circ.
- Offset transition, rect. to rect.
- Offset transition, rect. to circ.
- Offset transition, circ. to rect.
- Offset transition, circ. to circ.
- Flexible connection, rect. duct
- Flexible connection, circ. duct
- Flexible connection 2, rect. duct
- Flexible connection 2, circ. duct
- Supply, rect. duct toward
- Supply, rect. duct away
- Supply, rect. duct, elbow away
- Supply, circ. duct toward
- Supply, circ. duct away
- Supply, circ. duct, elbow away
- Return, rect. duct toward
- Return, rect. duct away
- Return, rect. duct, elbow away
- Return, circ. duct toward
- Return, circ. duct away
- Return, circ. duct, elbow away
- Sliding damper, rect. duct
- Sliding damper, circ. duct
- Damper, ACD
- Damper, BD
- Damper, FD/AD
- Damper, MD
- Damper, SD/AD
- Vert. duct, rect. duct toward
- Vert. duct, rect. duct away
- Vert. duct, rect. duct, elbow away
- Vert. duct, circ. duct toward
- Vert. duct, circ. duct away
- Vert. duct, circ. duct, elbow away
- VAV box
