Office cubicles plan

This office floorplan sample shows cubicles and office supplies layout. "A cubicle is a partially enclosed office workspace that is separated from neighboring workspaces by partitions that are usually 5–6 feet (1.5–1.8 m) tall. Its purpose is to isolate office workers and managers from the sights and noises of an open workspace so that they may concentrate with fewer distractions. Cubicles are composed of modular elements such as walls, work surfaces, overhead bins, drawers, and shelving, which can be configured depending on the user's needs. Installation is generally performed by trained personnel, although some cubicles allow configuration changes to be performed by users without specific training. Cubicles in the 2010s are usually equipped with a computer, monitor, keyboard and mouse on the work surface. Cubicles typically have a desk phone. Since many offices use overhead fluorescent lights to illuminate the office, cubicles may or may not have lamps or other additional lighting. Other furniture that is often used in cubicles includes an office chair, a filing cabinet for locking documents away, a bookcase and a coatrack." [Cubicle. Wikipedia] The floorplan example "Office cubicles plan" was created using ConceptDraw DIAGRAM software extended with Office Layout Plan solition from Building Plan area of ConceptDraw Solution Park.
Layout example
Layout example, wastepaper basket, square waste can, waste can, stool, stadium, portable wall partition, pendant lamp, partition screen, office wall divider, office table, round, newspaper rack, letter tray, keyboard, headset, graphics tablet, file cabinet, cubicle workstation 6'x8', circle, cabinet, all-in-one computer, MacBook Air,
